Features
• Minimum flow rate as low as 5 cc/min, suitable for ultra-low flow control.
• Highly accurate flow control with repeatability within ±1%.
• Multiple model options featuring high-precision ceramic cylinders.
• Durable, wear-resistant coated piston rods for excellent lifetime.
• Excellent compatibility with coatings containing high solid content.
• Reduces up to 80% of flushing waste compared to traditional proportioning systems.
• Minimizes material mixing volume—ideal for short pot-life materials.
• Faster color change with less cleaning required, reducing waste and downtime.
• Auto Parts
• Furniture & Wood Finishing
• Sanitary Ceramics & Bathroom Products
•3C
•General Industrial: Hardware, Plastics, and More
TECHNICAL DATA TABLE
|
Designation |
Value |
|
Max Material Pressure (Low-Pressure System) |
300 psi (21 bar / 2.1 MPa) |
|
Max Material Pressure (High-Pressure System) |
1500 psi (105 bar / 10.5 MPa) |
|
Max Air Pressure |
100 psi (7 bar / 0.7 MPa) |
|
Minimum Flow Rate |
≤5 cc/min |
|
Flow Range |
5–700 cc/min |
|
Repeatability |
±1% |
|
Viscosity Range |
20–5000 cps |
|
Noise |
<75 dB(A) |
|
Power Supply |
AC 220 V, 50–60 Hz, 4 A |
|
Operating Temperature |
5–50°C (41–122°F) |
|
Dimensions |
Wall-mounted split type: 520mm × 560mm × 2000mm (reference) |
|
Appy Materials |
Single-component, solvent-based and water-based coatings, polyurethane, epoxy, acid-catalyzed varnish, etc. |
|
Wetted Parts |
316 Stainless Steel, Ceramics, Composite Materials, FFKM, PTFE |
